20204, Kit MTP® Universal, 3.0 MM Round, Male Single-mode Elite, Yellow Housing, 20N Spring Force
Features
Elliptical guide pin tip to minimize ferrule debris
Exceeds TIA and IEC dimensional requirements for optimal performance
Floating ferrule design ensures fiber contact integrity
Highest precision SS guide pins
Industry leading lowest loss Insertion Loss when used with MT Elite® Ferrules
Removable housing for interferometry and rework
Applications
Array fiber to single fiber breakouts and cassettes
Array trunk cables
FTTh (home) MDU cabling
Parallel optic patch cables: SR-4, SR-8 & PSM4
Qualified to GR-1435 service life
Qualified to TIA-568.3-D
Standards Compliance IEC 61754-7-1; 61754-7-2
Standards Compliance TIA 604-5
Structured cabling per TIA-942 & TIA-568
Specifications
Part Number
20204
Brand
MTP®
Type
Plug
Plug Performance
MTP Elite®
Key Orientation
Standard - TIA-604-5
Fiber Type
Single-mode
Gender
Male
Spring Force
20N
Fiber Count
2x12 (20N)
Housing Color
Yellow
Cable Style
3.0 mm
Operating Environment
Controlled
Cable Exit Type
Standard Boot
Style
MPO
Downloads
Drawing
C20182.pdf
Literature
MTP_Solutions_Brochure
Kit Bill of Materials
Component Part Number
Description
Drawing
Component Part Number
8041
Description
Boot_Black_MTP®_3.0mm
Drawing
C8041.pdf
Component Part Number
15633
Description
Crimp Band_MTP®_3.0 mm
Drawing
C15633.pdf
Component Part Number
19692
Description
Spring Push_Universal_3.0mm
Drawing
C19692.pdf
Component Part Number
17698
Description
Spring_MTP®_Universal Seat_20N
Drawing
C17698.pdf
Component Part Number
17801
Description
Pin-Clamp_SM_ELT_MTP®Universal
Drawing
C17801.pdf
Component Part Number
16918
Description
Hsg_Yellow_MTP®
Drawing
C10074.pdf
Component Part Number
17242
Description
Dust Cap_MTP®
Drawing
C17242.pdf
Related Products
8202, MTP® Round Crimp Tool, 3.0mm
8173, MTP® Round Crimp Die, 3.0
400053-01, Crimp Hand Tool
18476, MTP® Housing Removal Tool, Universal
17150, Ferrule Insertion Cap, MTP®-16
17669, IBC™ Brand Cleaner MTP®-16
