Features
- <= 12Fibers per row
- 0.7mm guide pins; 4.6mm guide pin pitch
- High Density; fiber pitch: 0.25mm
- Highly glass filled for dimensional stability and stable environmental performance
- Low hygroscopic PPS material for stable environmental performance
- Low insertion loss optimized for 40G, 100G and 400G link applications
- Mold marks to indicate fiber type, fiber count and performance
Applications
- FTTx hardened connector cabling infrastructure
- MTP® brand MPO cable assemblies
- Optical backplane connectivity for OBO architectures
- Standards Compliance IEC 61754-5
- Standards Compliance IEC 61754-7-1; 61754-7-2
- Standards Compliance TIA 604-5
Specifications
Part Number
18182
Brand
MT
Performance
MT Elite®
Fiber Type
Single-Mode Elite
Fiber Count
2x12
Endface Type
Pre-Angle Ferrule
Polish Type
APC
Fiber Cladding Size
125 micron
Downloads
Drawing
Literature
Kit Bill of Materials
Component Part Number
Description
Drawing
