Features
- 0.55mm guide pins; 5.3mm guide pin pitch
- 16 Fibers per row
- High Density; fiber pitch: 0.25mm
- Highly glass filled for dimensional stability and stable environmental performance
- Low hygroscopic PPS material for stable environmental performance
- Low insertion loss optimized for 40G, 100G and 400G link applications
- Mold marks to indicate fiber type, fiber count and performance
Applications
- FTTx hardened connector cabling infrastructure
- MTP 16™ brand MPO-16 cable assemblies
- Optical backplane connectivity for OBO architectures
- Standards Compliance IEC 61754-7-3; 61754-7-4
- Standards Compliance TIA 604-18
Specifications
Part Number
18732
Brand
MT-16
Performance
MT Elite®
Fiber Type
Single-Mode Elite
Fiber Count
1x16
Endface Type
Pre-Angle Ferrule
Polish Type
APC
Fiber Cladding Size
125 micron
Downloads
Drawing
Literature
Kit Bill of Materials
Component Part Number
Description
Drawing
