Features
- 19mm housing & DirectConec boot allows for tight connector spacing
- Blind mate features prevent ferrule contamination during insertion & removal
- Mates with other HEC-DC connectors via inline adapter
- Mates with traditional SC connectors via hybrid adapter
- Qualified to GR-3120 as well as IEC 61753-1 OP+ Cat A, G ,S
- Simple yet secure removal via twist-n-pull boot
- Straightforward push-n-click insertion
- Supports 4.0mm to 6.5mm round cable
- Version supporting flat drop cables coming soon
- Withstands 100lbf/450N pull force
Applications
- Broadcast
- Fiber to the Antenna (FTTA)
- Fiber to the Home (FTTH)
- Industrial
- Long-Haul Security Applications
- Solar & Wind Energy System Monitoring and Management
Specifications
Part Number
25377
Brand
HEC-DC
Type
Plug
Style
HEC-DC SC
Fiber Type
Single-mode
Fiber Count
1
Polish Type
PC
Housing Color
Black
Boot Color
Black
Cable Style
4.0-6.5 mm Round
Cable Exit Type
Twist-Pull Boot
Insertion Extraction
Push, Twist-Pull Boot
